Multi Jet Dry Dial Plastic Water Meter
Sètifika: ISO9001: 2000 Kalite Sistèm Sètifika
Application
Measuring the volume of cold potable water passing through the pipeline.
Plastik Dlo Meter Karakteristik
Completely plastic shell, solid and robust design, long service guaranteed.
High quality materials corrosion resistance.
Pole ring magnet polymer coating as protection against deposits.
The measuring mechanism can be exchanged.
Anti-magnet.
Inside calibration device.
Large measuring range high flow accuracy.
Steady curve characteristics.
Measuring accuracy is up to ISO4064, Class B.
Debit Surcharge: QS=2Qp (Qn=debit nominal)
KONDISYON TRAVAY
Water temperature: Less than or equal to 40ºC
Presyon dlo: mwens pase oswa egal a 1.6MP (16bar)
ERÈ MAXIMUM KI ADMISIB
In the lower zone from qmin inclusive up to but excluding qt is ± 5 percent
In the upper zone from qt inclusive up to and including QS is ± 2 percent
Akseswa
Optional: Both brass thread connections and plastic thread connections are available.
